80-80-38 DC Axial Fans

Bearing Type:Two Ball BearingsMaterial:Impeller & Frame: Plastic (UL94V-0)Lead Wires:UL1007#AWG26 Red Wire Positive (+) Black Wire Negative (一)Weight:210.0g80*80*38 DC Axial Fans

Bearing Type: Two Ball Bearings

Material: Impeller & Frame: Plastic (UL94V-0)

Lead Wires: UL1007#AWG26

                     Red Wire Positive (+)

                     Black Wire Negative (一)

Weight: 210.0g

80*80*38 DC Axial Fans Specifications

Air volume/pressure curve
Air volume/pressure curve
Product appearance size
Product appearance size

80*80*38 DC Axial Fans Major Characteristic Parameters

MODELBearing
System
Rated
Voltage
Operating
Voltage
Range
Input
Current
SpeedMaximum
Air Flow
Maximum
Air Pressure
Noise
PART NOB/S/FVDEVDEAMPRPMCFMMmH2ODb-A
WSA08038_12JB127.0~13.20.4420058.210.445
WSA08038_24JB2414.0~26.40.25420058.210.445
WSA08038_48LB4828.0~56.00.14420058.210.445
WSA08038_12LB127.0~13.20.51490069.114.249
WSA08038_24LB2414.0~26.40.41490069.114.249
WSA08038_48LB4828.0~56.00.23490069.114.249
WSA08038_12MB127.0~13.20.6520078.819.353
WSA08038_24MB2414.0~26.40.55520078.819.353
WSA08038_48MB4828.0~56.00.33520078.819.353
WSA08038_12HB127.0~13.20.85610084.822.756
WSA08038_24HB2414.0~26.40.78610084.822.756
WSA08038_48HB4828.0~56.00.51610084.822.756
WSA08038_12UB127.0~13.21.557500105.534.562
WSA08038_24UB2414.0~26.41.777500105.534.562
WSA08038_48UB4828.0~56.00.587500105.534.562
WSA08038_12VB127.0~13.22.6900013050.965.5
WSA08038_24MB2414.0~26.41.8900013050.965.5
WSA08038_24MB4828.0~56.00.9900013050.965.5
