80-120mm DC Axial Fans

WHEE DC axial fans are widely used in mechanical heat dissipation due to their advantages of good heat dissipation effect, long service life, simple structure and easy installation. We offer quality DC axial flow fans from 80mm to 120mm. All our DC axial cooling fans are designed to meet UL, CUL and CE standards. Find specially designed axial fan supplied by the certified axial fans manufacturer from China.

80-120mm DC Axial Fans Functions


  • FG: FG Signal

  • RD: RD Signal

  • PWM: PWM Signal

  • VC: Voltage Control

  • TC: Temperature Control


80-120mm DC Axial Fans Specifications


BEARING TYPEF.D. Bearing /One ball /Sleeve bearing/ Two ball
FRAMEP B T. UL94V-0
IMPELLERP B T. UL94V-0
P C BUL94V-0
MATERIAL LISTRoHS Compliant
OPERATING TEMPERATURE-10 ℃ ~  + 70 ℃
STORAGE TEMPERATURE-40 ℃ ~  + 70 ℃
DIELETRIC STRENGTHApplied a 500VAC for 1.0 minute or 600VAC for 2 seconds between housing and both lead wires.
INSULATION RESISTANCEAt least 10 MΩ at 500VDC between internal stator and both lead wires.
LIFE EXPECTANCY30,000(S)/40,000(F)/50,000 hrs(2B) in running conditions at 40℃ ambient.
